P 1.2
- LED Chip – Nationstar
- Driver IC – MBI 5153 / ICN2053
- Refresh Rate – 3840 Hz
- Lamp – SMD 1010
- Pixel Density – 640,000 dots/m²
- Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
- Cabinet Resolution – 512 x 384 pixels / 480 x 270 pixels
- Cabinet Material – Magnesium / Aluminum Die-cast
- Brightness – 800 – 1000 nits
- Protection Level – IP 57
- Power Supply – Mean well / G-Energy
- Maintenance – Front / Back
- Viewing Angle – 178 H – 160 V
- Viewing Distance – 1.25M – 100M
- Control System – Novastar / Colorlight
P 1.5
- LED Chip – Nationstar
- Driver IC – MBI 5153 / ICN2053
- Refresh Rate – 3840 Hz
- Lamp – SMD 1010
- Pixel Density – 443,556 dots/m²
- Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
- Cabinet Resolution – 416 x 312 pixels / 384 x 216 pixels
- Cabinet Material – Magnesium / Aluminum Die-cast
- Brightness – 800 – 1000 nits
- Protection Level – IP 57
- Power Supply – Mean well / G-Energy
- Maintenance – Front / Back
- Viewing Angle – 178 H – 160 V
- Viewing Distance – 1.5M – 100M
- Control System – Novastar / Colorlight
P 1.6
- LED Chip – Nationstar
- Driver IC – MBI 5153 / ICN2053
- Refresh Rate – 3840 Hz
- Lamp – SMD 1010
- Pixel Density – 362,404 dots/m²
- Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
- Cabinet Resolution – 384 x 288 pixels / 360 x 200 pixels
- Cabinet Material – Magnesium / Aluminum Die-cast
- Brightness – 800 – 1000 nits
- Protection Level – IP 57
- Power Supply – Mean well / G-Energy
- Maintenance – Front / Back
- Viewing Angle – 178 H – 160 V
- Viewing Distance – 1.6M – 100M
- Control System – Novastar / Colorlight
P 1.8
- LED Chip – Nationstar
- Driver IC – MBI 5153 / ICN2053
- Refresh Rate – 3840 Hz
- Lamp – SMD 1515
- Pixel Density – 288,400 dots/m²
- Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
- Cabinet Resolution – 344 x 258 pixels / 320 x 180 pixels
- Cabinet Material – Magnesium / Aluminum Die-cast
- Brightness – 800 – 1000 nits
- Protection Level – IP 57
- Power Supply – Mean well / G-Energy
- Maintenance – Front / Back
- Viewing Angle – 178 H – 160 V
- Viewing Distance – 1.8M – 100M
- Control System – Novastar / Colorlight
P 2.5
- LED Chip – Nationstar
- Driver IC – MBI 5153 / ICN2053
- Refresh Rate – 3840 Hz
- Lamp – SMD 1515
- Pixel Density – 160,000 dots/m²
- Cabinet Size – 640 mm x 480 mm
- Cabinet Resolution – 256 x 192 pixels
- Cabinet Material – Magnesium / Aluminum Die-cast
- Brightness – 800 – 1000 nits
- Protection Level – IP 57
- Power Supply – Mean well / G-Energy
- Maintenance – Front / Back
- Viewing Angle – 178 H – 160 V
- Viewing Distance – 2.5M – 100M
- Control System – Novastar / Colorlight
