P 1.2

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1010
  • Pixel Density – 640,000 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 512 x 384 pixels  /  480 x 270 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.25M – 100M
  • Control System – Novastar / Colorlight

P 1.5

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1010
  • Pixel Density – 443,556 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 416 x 312 pixels  /  384 x 216 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.5M – 100M
  • Control System – Novastar / Colorlight
TRICOLOR LED

P 1.6

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1010
  • Pixel Density – 362,404 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 384 x 288 pixels  /  360 x 200 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.6M – 100M
  • Control System – Novastar / Colorlight

P 1.8

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1515
  • Pixel Density – 288,400 dots/m²
  • Cabinet Size – 640 mm x 480 mm / 600 mm x 337.5 mm
  • Cabinet Resolution – 344 x 258 pixels  /  320 x 180 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 1.8M – 100M
  • Control System – Novastar / Colorlight

P 2.5

  • LED Chip – Nationstar
  • Driver IC – MBI 5153 / ICN2053
  • Refresh Rate – 3840 Hz
  • Lamp – SMD 1515
  • Pixel Density – 160,000 dots/m²
  • Cabinet Size – 640 mm x 480 mm
  • Cabinet Resolution – 256 x 192 pixels
  • Cabinet Material – Magnesium / Aluminum Die-cast
  • Brightness – 800 – 1000 nits
  • Protection Level – IP 57
  • Power Supply – Mean well / G-Energy
  • Maintenance – Front / Back
  • Viewing Angle – 178 H – 160 V
  • Viewing Distance – 2.5M – 100M
  • Control System – Novastar / Colorlight
×
